AIR OPERATED DIAPHRAGM PUMPS
Our AODD pumps, ranging from 1/2″ – 3″ are built for demanding mining environments. AODD pumps use compressed air to safely transfer water, chemicals, oils, slurries and other fluids—delivering reliable, versatile pumping.
D152 1/2″ Diaphragm Pump
- Max Flow Rate: 65 L/min.
- Liquid Connections: 12″ Female Multiports.
- Max Slurry Size: 2.0 mm (Ball Valve Models).
- Max Suction Lift: Dry Flat Valve: 2.0m. Ball Valve: 1.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.7 MPa.
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, One-piece PTFE.
- Air Motor Material: PPG. (Optional CFPP).
- Description: 12″ AODD Pumps available in a full range of materials. Looped C® Spring Air Spool. Polypropylene Air Motor. Multi Port Threaded Connections. Internal Silencer. Multi Footprint.
D200 Metallic 3/4″ Metallic Diaphragm Pump
- Max Flow Rate: 210 L/min. (Rubber)
- Liquid Connection Size: 3/4″.
- Max Slurry Size: 6.5 mm.
- Max Suction Lift: PTFE Dry: 1.5m Rubber Dry: 4.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.7 MPa.
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, EPDM, FKM, One-piece PTFE
- Air Motor Material: PPG (Optional CFPP & Aluminium)
- Air Motor Model: Looped CR Spring Air Spool
- EExhaust Configuration: External Plastic Exhaust Silencer
- Base & Footprint: Heavy Duty Steel Legs.
D250 Metallic 1″ Metallic Diaphragm Pump
- Max Flow Rate: 220 L/min. (Rubber)
- Liquid Connection Size: 1″
- Max Slurry Size: 6.5 mm.
- Max Suction Lift: PTFE Dry: 1.5m Rubber Dry: 4.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.7 MPa
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, EPDM, FKM, One-piece PTFE
- Air Motor Material: PPG (Optional CFPP & Aluminium)
- Air Motor Model: Looped CR Spring Air Spool
- Exhaust Configuration: External Plastic Exhaust Silencer
- Base & Footprint: Heavy Duty Steel Legs & Fully Adjustable Footprint
D400 Metallic 1 1/2″ Metallic Diaphragm Pump
- Max Flow Rate: 600 L/min. (Rubber Fitted)
- Liquid Connections: 11/2″ Female Threaded / Flanged Centre Ports.
- Max Slurry Size: 8.0mm.
- Max Suction Lift: PTFE Dry: 3.0m Rubber Dry: 5.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.85 MPa. (Rubber)
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, EPDM, FKM, One-piece PTFE.
- Air Motor Material: Aluminium.
- Description: 11/2″ Metallic AODD Pumps available in Al, SUS. Looped CR Spring Air Spool.
- Aluminium Air Motor. Choice of Threaded & Flanged Centre Port Connections. Ball Check Valves. External Plastic Silencer.
D500 Metallic 2″ Diaphragm Pump
- Max Flow Rate: 800 L/min. (Rubber)
- Liquid Connection Size: 2″ Female Threaded / Flanged Centre Ports.
- Max Slurry Size: 8.0 mm.
- Max Suction Lift: PTFE Dry: 3.0m Rubber Dry: 5.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.85 MPa. (Rubber)
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, EPDM, FKM, One-piece PTFE.
- Air Motor Material: Aluminium.
- Description: 2″ Metallic AODD Pumps available in Al, SUS. Looped C® Spring Air Spool. Aluminium Air Motor. Choice of Threaded & Flanged Centre Port Connections. Ball Check Valves. External Plastic Silencer.
D800 Metallic 3″ Diaphragm Pump
- Max Flow Rate: 1050 L/min. (Rubber)
- Liquid Connection Size: 3″ Female Threaded / Flanged Centre Ports
- Max Slurry Size: 10.0 mm.
- Max Suction Lift: PTFE Dry: 3.0m Rubber Dry: 5.5m. Wet (Primed): 8.0m.
- Max Discharge Pressure: 0.85 MPa. (Rubber)
- Diaphragm Options: PTFE, CR, NBR, TPEE, TPO, EPDM, FKM, One-piece PTFE.
- Description: 3″ Metallic AODD Pumps available in Al, SUS. Looped C® Spring Air Spool. Aluminium Air Motor. Choice of Threaded & Flanged Centre Port Connections. Ball Check Valves. External Plastic Silencer.
